Multi-pressure tester question
#1
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
Multi-pressure tester question
The facrory manual suggests using a multi-pressure tester, which might help me solve my problem, but I can't seem to find them on the internet anywhere. Do they have a more specific name?
#3
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
well I'm about to replace a fuel filter, but also I have a fuel problem that won't let my car start and I was thinking maybe a pressure tester would be able to narrow down the problem.
#5
Lives on the Forum
![](https://www.rx7club.com/images/misc/10_year_icon.png)
Yeah, any pressure tester that can handle the gasoline should be okay.
Since this is just spot testing, you don't have to worry about safety issues on running a line with fuel in it into the interior!
In a pinch, you can use an oil pressure gauge!
Something that reads up to 100psi should be fine.
Good luck!
-Ted
Since this is just spot testing, you don't have to worry about safety issues on running a line with fuel in it into the interior!
In a pinch, you can use an oil pressure gauge!
Something that reads up to 100psi should be fine.
Good luck!
-Ted
#6
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
Sounds simple, but i have one more question. A Self-diagnosis checker, the manual says I can test fuel/air ratio and stuff but I looked them up and they seem pretty expensive. Any suggestions on those?
#7
Retired Moderator, RIP
![](https://www.rx7club.com/images/misc/10_year_icon.png)
iTrader: (142)
Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes
on
114 Posts
It could be as simple as a flooded engine..and if you check the plugs and find out they are Wet then it just may be,That could be why you are not starting..you can go ahead and change the fuel filter but I would suggest to look up Deflooding,and also How to do a Compression Check using a conventional piston engine compression tester,to see what kind of shape your internals are in..my 2 cents
Trending Topics
#8
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
I think your right on that, I've been deflooding it for the past couple of hours by pulling the egi fuses and about 15 minutes ago it kicked over for about 5 seconds. I tested the fuel pressure and it was around 45psi, is that a good number?
#9
I'm a boost creep...
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Join Date: Jan 2002
Location: Auckland, New Zealand
Posts: 15,608
Likes: 0
Received 8 Likes
on
8 Posts
Sounds far too high. It should idle at ~28psi and even with the vac hose pulled off the regulator it should only be ~36psi. That's measuring the pressure after the fuel filter.
#10
HAILERS
![](https://www.rx7club.com/images/misc/10_year_icon.png)
Join Date: May 2001
Location: FORT WORTH, TEXAS,USA
Posts: 20,563
Likes: 0
Received 22 Likes
on
20 Posts
Originally Posted by Ironman311
I think your right on that, I've been deflooding it for the past couple of hours by pulling the egi fuses and about 15 minutes ago it kicked over for about 5 seconds. I tested the fuel pressure and it was around 45psi, is that a good number?
If I were you, I'd do one of two things. Either make a fuel cut switch right now, or disconnect the fuel pump plug that is under the rear strut tower carpet.
In my Humble opinion, I (lots of I in my posts) think you should leave all the fuses in while cranking the engine but cut the fuel pump out of your starting procedure.
For fuel, buy two cans of starter fluid. Spray in the intake filter for two seconds, no more. Start the car. You now have fuel AND spark at the same time. Nothing but good things can happen.
If it starts for a moment, then do it again a couple of times before reconnecting the fuel pump.
I've other opinions about starting cars that are flooded, but that's for later if it won't start doing the above.
By the way, take a look and see if the water thermo sensor is connected at the back of your water pump Housing. Green jack on it.
#11
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
I'll try the starter fluid today for sure, it's close to turning over and probably just needs the extra bang. As for the fuel pressure being too high, how can I bring it down?
#12
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
This is starting to seem even worse, even after a lot more attempts to unflood the engine and trying starter fluid it still refuses to turn over all the way. I've had one long sputter tonight but I'm doubting it will turn over and I'm starting to think the problem might be electrical. any thoughts?
#14
Junior Member
![](https://www.rx7club.com/images/misc/05_year_icon.png)
Thread Starter
Join Date: Jul 2005
Location: California
Posts: 36
Likes: 0
Received 0 Likes
on
0 Posts
Update: It finally started. and kept running. Now the only problem is when I hit the gas it loses a lot of power, almost dies, I have to pump the gas to get it revved up and it absolutely refuses to go past 5krpm. There's smoke coming from the turbo and the exhaust is loudest under the passenger seat. I'm suspecting an exhaust leak and possibly a bad spark plug.
