Electronic transmission speed sensor
#1
Electronic transmission speed sensor
Has anyone figured out a way to replace the factory speedo cable with an electronic sensor? IIRC the stock one is pressed on making it difficult to remove and press onto a FD sensor. Fd sensors don't work since the gears are the opposite spiral profile(?) and would not work.
I want to say I recall a potential Honda/Toyota one working but never got that car.
I want to say I recall a potential Honda/Toyota one working but never got that car.
#2
Rotary Freak
https://www.rx7club.com/2nd-generati.../#post10941669
Clokker was able to swap the gear a few years back. Otherwise you could get one of the Dakota Digital boxes that converts the cable to a VSS signal, or (the free option) tap the green/red wire coming from the speedometer in the cluster (conveniently located at the cruise control computer plug as well) since the speedometer generates a VSS signal. Either of those solutions doesn't really eliminate the cable, but they do get you a VSS signal.
Clokker was able to swap the gear a few years back. Otherwise you could get one of the Dakota Digital boxes that converts the cable to a VSS signal, or (the free option) tap the green/red wire coming from the speedometer in the cluster (conveniently located at the cruise control computer plug as well) since the speedometer generates a VSS signal. Either of those solutions doesn't really eliminate the cable, but they do get you a VSS signal.
#3
Senior Member
![](https://www.rx7club.com/images/misc/15_year_icon.png)
![](https://cimg6.ibsrv.net/gimg/www.rx7club.com-vbulletin/640x480/rkusahkl_ec501192172839d6b4a1be423515bdd7aea5d730.jpg)
This is the solution I am using. It's a dakota digital VR sensor, I believe they list it as GM compatible 8k ppm sensor. FD sensors are expensive used , hard to find, and as mentioned need the gear replaced with the FC one to be used in the FC trans.
This also requires some diy to make it work,but it's relatively easy to do. You need to rob the tang tip of the FC cable To either braze or solder on. Basically you drill The FC tang tip out to just fit the size of the supplied square keyway piece. Then you either braze or solder it . I brazed it with silver solder. But silver solder and the flux is expensive. I'm sure you could solder it with modern plumbing solder and it would be plenty strong to do the job.The other note is the dakota digital has a 7/8-18 imperial thread, the FC trans is M22x1.5. I thought I was going to have to work some sort of different adapter and read online where the 7/8 thread will thread on a couple of turns as a bs way to make it work. Actually it threads on quite far when I tried it and was relieved that I didn't need to dick with making some sort of adaptor.
The pluses are these sensors are cheap at around $40,and bolt in to the FC trans without having to do anything but take the cable end off. The downside is you need to rob a tang off a FC, FB , or miata cable and do a little bit of DIYing.
Last edited by Nosferatu; 07-04-24 at 12:11 PM.
The following users liked this post:
driftxsequence (07-06-24)
#4
https://www.rx7club.com/2nd-generati.../#post10941669
Clokker was able to swap the gear a few years back. Otherwise you could get one of the Dakota Digital boxes that converts the cable to a VSS signal, or (the free option) tap the green/red wire coming from the speedometer in the cluster (conveniently located at the cruise control computer plug as well) since the speedometer generates a VSS signal. Either of those solutions doesn't really eliminate the cable, but they do get you a VSS signal.
Clokker was able to swap the gear a few years back. Otherwise you could get one of the Dakota Digital boxes that converts the cable to a VSS signal, or (the free option) tap the green/red wire coming from the speedometer in the cluster (conveniently located at the cruise control computer plug as well) since the speedometer generates a VSS signal. Either of those solutions doesn't really eliminate the cable, but they do get you a VSS signal.
I'm hoping to use a full digital cluster so that won't exactly work but this also leads me to believe that if the gear fits the trans like he mentioned then I can just change the data to match in the megasquirt. I was under the assumption the helix of the gear being backwards wouldn't be compatible.
#5
Senior Member
![](https://www.rx7club.com/images/misc/15_year_icon.png)
If you are planning to use the FD sensor this sensor will work. the FD VR sensor is 8200ppm vrs. the digital dakota of 8k. This works as I grafted a FD cluster into the FC dash. this sensor works on the FD speedo perfectly. Don't ask why, it was a miserable time consuming project. Turned out cool but the juice was not worth the squeeze.
#6
Rotary Freak
I'm hoping to use a full digital cluster so that won't exactly work but this also leads me to believe that if the gear fits the trans like he mentioned then I can just change the data to match in the megasquirt. I was under the assumption the helix of the gear being backwards wouldn't be compatible.
#7
Senior Member
![](https://www.rx7club.com/images/misc/15_year_icon.png)
I forgot about this one when I was originally searching for a sensor. Pretty sure it's a bolt in solution if you have a programable speedo or aren't stuck on using a 8 pulse VR sensor as in my case. It's a toyota 4 pulse "hall" 3 wire sensor. Has the same tang and is a M22x1.5 thread.
Driftmotion VSS Vehicle Speed Sensor
Driftmotion VSS Vehicle Speed Sensor
Trending Topics
#8
I forgot about this one when I was originally searching for a sensor. Pretty sure it's a bolt in solution if you have a programable speedo or aren't stuck on using a 8 pulse VR sensor as in my case. It's a toyota 4 pulse "hall" 3 wire sensor. Has the same tang and is a M22x1.5 thread.
Driftmotion VSS Vehicle Speed Sensor
Driftmotion VSS Vehicle Speed Sensor
