12a79

i am looking for an exhaust manifold to make a draw thru turbo 12a i found some for 13b but i wont to work on my 12a if u know anyone who has one or has one for sale please send a message . also how many horses do u think i can get out of a draw thru set up with the nikki carb?im also looking for a delorto side draft or a weber dosent matter please help me

12a79

1

FB II

i think you have your ideas mixed up. you need to do more research. and stop using the 1 to bring your threads back to the top.

79+80+84_rx-7

what turbo do you plan on running?

REVHED

The exhaust manifold has absolutely nothing to do with whether it's draw-through or blow-through.

FB II

lol, like i said he's lost. he needs to search more and stop making multiple threads with the same question but different title.

wecycle

stock CFM for the carb is 315 +-
If you were to run 15 psi boost you would need roughly twice that. (say 600 cfm)
This is clearly in the range of typical Holley carbs. A vaccum secondary such as a 3310 (750 cfm) would be likely to suit this setup since the scondaries will only open as needed. With 15 psi of boost you had better be thinking of how to intercool it or at least set up a boost triggered water injection. keep us posted on you progress. Once you get it running be sure you creep up in one pound increments of boost and do many many plug checks to detect detonation. Remember you are trying to build a performance engine, not a grenade.

trochoid

iTrader: (6)

The stock FC turbo manifold can be adapted to fit the 12a. There are write-ups on it, may even be in the archives. Sounds like you need to do a lot more research and searching, and buy the book on turbos by Corky Bell. Maximum Boost

If you are looking for more than 6-8 psi, you will need to do a blow-through system, with an intercooler.

Good luck.

REVHED

Just so you know, stated carb CFM measurements don't mean jack **** when under boost. ie, any given carb will flow way more when under increased pressure.

12a79

im asking for help i didnt get enough info the other day im not trying to b at the top of ne list i just want some experience to speak to me

FB II

https://www.rx7club.com/1st-gen-archive-71/engine-turbo-rotary-part-s-prices-396506/

https://www.rx7club.com/1st-gen-archive-71/engine-how-build-high-output-12a-turbo-without-blowing-up-your-motor-380353/

you'll need this if you use the stock carb:
https://www.rx7club.com/1st-gen-archive-71/intake-nikki-carburetor-rebuilding-tips-238032/

and this will be your bible for now if you choose blow thru: (which it seems you are still undecided)
https://www.rx7club.com/1st-gen-archive-71/engine-12a-turbo-write-up-116768/

this should be a good bit to read and will definately help you get started. noone is mad at you for asking, but with only 14 posts (as of this thread) you need to hit up the SEARCH button FIRST.

i found all this info in the ARCHIVES. every question you've asked related to your turbo setup wanting...... has been covered 5,000 times. now, when you get closer and want opinions we're here to help

680RWHP12A

i spoke with the guy already.... very confused individual, ...... needs to eat more cheese

FB II

hahaha, awesome. i think he'll be ok once he's got a brick of cheddar in his system oh and robert... the air bleeds are rockin! CHEESE FOR EVERYONE!

tunafish

Hey 12a you want one of these dont you

tunafish

heres the picture

680RWHP12A

bad ***!!!!!!!!!!!!!!!!!!!!

Hyper4mance2k

iTrader: (40)

evil_motors

iTrader: (3)

lol that is awesome

perfect_circle

680, i want that carb hat, if you can get me some pics sent.
