i need help draw thru turbo 12a
#1
Full Member
Thread Starter
Join Date: Jun 2005
Location: compton, ca.
Posts: 124
Likes: 0
Received 0 Likes
on
0 Posts
i need help draw thru turbo 12a
i am looking for an exhaust manifold to make a draw thru turbo 12a i found some for 13b but i wont to work on my 12a if u know anyone who has one or has one for sale please send a message . also how many horses do u think i can get out of a draw thru set up with the nikki carb?im also looking for a delorto side draft or a weber dosent matter please help me
#6
Banned. I got OWNED!!!
Join Date: Dec 2002
Location: wishing i was back in FL
Posts: 4,192
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by FB II
i think you have your ideas mixed up. you need to do more research. and stop using the 1 to bring your threads back to the top.
lol, like i said he's lost. he needs to search more and stop making multiple threads with the same question but different title.
#7
Senior Member
Join Date: Jul 2004
Location: Delhi, CA
Posts: 444
Likes: 0
Received 0 Likes
on
0 Posts
turbo
stock CFM for the carb is 315 +-
If you were to run 15 psi boost you would need roughly twice that. (say 600 cfm)
This is clearly in the range of typical Holley carbs. A vaccum secondary such as a 3310 (750 cfm) would be likely to suit this setup since the scondaries will only open as needed. With 15 psi of boost you had better be thinking of how to intercool it or at least set up a boost triggered water injection. keep us posted on you progress. Once you get it running be sure you creep up in one pound increments of boost and do many many plug checks to detect detonation. Remember you are trying to build a performance engine, not a grenade.
If you were to run 15 psi boost you would need roughly twice that. (say 600 cfm)
This is clearly in the range of typical Holley carbs. A vaccum secondary such as a 3310 (750 cfm) would be likely to suit this setup since the scondaries will only open as needed. With 15 psi of boost you had better be thinking of how to intercool it or at least set up a boost triggered water injection. keep us posted on you progress. Once you get it running be sure you creep up in one pound increments of boost and do many many plug checks to detect detonation. Remember you are trying to build a performance engine, not a grenade.
Trending Topics
#8
Old Fart Young at Heart
iTrader: (6)
The stock FC turbo manifold can be adapted to fit the 12a. There are write-ups on it, may even be in the archives. Sounds like you need to do a lot more research and searching, and buy the book on turbos by Corky Bell. Maximum Boost
If you are looking for more than 6-8 psi, you will need to do a blow-through system, with an intercooler.
Good luck.
If you are looking for more than 6-8 psi, you will need to do a blow-through system, with an intercooler.
Good luck.
#9
Hunting Skylines
Join Date: Apr 2001
Location: Brisbane, Queensland, Australia.
Posts: 3,431
Likes: 0
Received 4 Likes
on
3 Posts
Originally Posted by wecycle
stock CFM for the carb is 315 +-
If you were to run 15 psi boost you would need roughly twice that. (say 600 cfm)
This is clearly in the range of typical Holley carbs. A vaccum secondary such as a 3310 (750 cfm) would be likely to suit this setup since the scondaries will only open as needed. With 15 psi of boost you had better be thinking of how to intercool it or at least set up a boost triggered water injection. keep us posted on you progress. Once you get it running be sure you creep up in one pound increments of boost and do many many plug checks to detect detonation. Remember you are trying to build a performance engine, not a grenade.
If you were to run 15 psi boost you would need roughly twice that. (say 600 cfm)
This is clearly in the range of typical Holley carbs. A vaccum secondary such as a 3310 (750 cfm) would be likely to suit this setup since the scondaries will only open as needed. With 15 psi of boost you had better be thinking of how to intercool it or at least set up a boost triggered water injection. keep us posted on you progress. Once you get it running be sure you creep up in one pound increments of boost and do many many plug checks to detect detonation. Remember you are trying to build a performance engine, not a grenade.
#11
Banned. I got OWNED!!!
Join Date: Dec 2002
Location: wishing i was back in FL
Posts: 4,192
Likes: 0
Received 0 Likes
on
0 Posts
https://www.rx7club.com/1st-gen-archive-71/engine-turbo-rotary-part-s-prices-396506/
https://www.rx7club.com/1st-gen-archive-71/engine-how-build-high-output-12a-turbo-without-blowing-up-your-motor-380353/
you'll need this if you use the stock carb:
https://www.rx7club.com/1st-gen-archive-71/intake-nikki-carburetor-rebuilding-tips-238032/
and this will be your bible for now if you choose blow thru: (which it seems you are still undecided)
https://www.rx7club.com/1st-gen-archive-71/engine-12a-turbo-write-up-116768/
this should be a good bit to read and will definately help you get started. noone is mad at you for asking, but with only 14 posts (as of this thread) you need to hit up the SEARCH button FIRST.
i found all this info in the ARCHIVES. every question you've asked related to your turbo setup wanting...... has been covered 5,000 times. now, when you get closer and want opinions we're here to help
https://www.rx7club.com/1st-gen-archive-71/engine-how-build-high-output-12a-turbo-without-blowing-up-your-motor-380353/
you'll need this if you use the stock carb:
https://www.rx7club.com/1st-gen-archive-71/intake-nikki-carburetor-rebuilding-tips-238032/
and this will be your bible for now if you choose blow thru: (which it seems you are still undecided)
https://www.rx7club.com/1st-gen-archive-71/engine-12a-turbo-write-up-116768/
this should be a good bit to read and will definately help you get started. noone is mad at you for asking, but with only 14 posts (as of this thread) you need to hit up the SEARCH button FIRST.
i found all this info in the ARCHIVES. every question you've asked related to your turbo setup wanting...... has been covered 5,000 times. now, when you get closer and want opinions we're here to help
#13
Banned. I got OWNED!!!
Join Date: Dec 2002
Location: wishing i was back in FL
Posts: 4,192
Likes: 0
Received 0 Likes
on
0 Posts
hahaha, awesome. i think he'll be ok once he's got a brick of cheddar in his system oh and robert... the air bleeds are rockin! CHEESE FOR EVERYONE!
